Product description

Product name and structure
Copper ingot casting machine, including frame, drive, transmission, mold, shunt, cooling and other parts.
1. The frame is composed of channel steel welding.
2. The drive consists of a motor, a reducer, front and rear chain wheels, and a coupling.
3. The transmission is composed of chain plates, rollers, and pins, with a pitch of 144.
4. The mold material is QT450-10.
5. The shunt is composed of tundish and shunt.
6. The cooling consists of water pipes, nozzles and valves.
Main technical parameters
1. Equipment size: (length*width*height) 10000*1200*1200 requires that the height of the water outlet of the middle package is not less than 1100 from the ground.
2. Copper ingot size; length, width and height 640*105*62±5, 120 pcs
3. Mould running speed: stepless speed regulation.
4. Motor power: 5.5KW in total.
Other parameters:
Operating speed; 0---3.04 m/min
Pouring method; automatic liquid dispensing
Cooling method; water spray

Why Choose Ruixinsheng Technology?

Independent Intellectual Property Rights:

Master the core technology and independent research and development of internationalleading induction heating system.

Energy-Saving and Efficient:

Meet international standards for electrical and load design standards, power factor up to0.98, and energy saving 20%.

Environmental Protection and Safety:

Furnace structure according to the national standards, scientific and technologicalreasonable personalized design, ensure the safety and reliability of the device.

Stable and Reliable:

The world's first-class component selection, scientific and reasonable equipmenttechnology, complete protection functions, the primary fault is close to zero.

Intelligent Control:

Equipment management system, can achieve production management, quality control andother functions, to achieve remote diagnosis of equipment, data acquisition, transmissionand other monitoring.
