Product description

Main Application: it is Suitable for quenching and tempering heat treatment of steel bars, low-carbon alloy steel, wind power bolts, anchor bolts, lead screws and hydraulic cylinder rods.
Power supply system: Quenching 160KW-3000KW/0.5-4KHz, tempering 100KW-3000KW/0.5-2.5KHz, hourly output 0.5-5 tons, applicable range ø20-ø100

Conveyor roller: The roller axis forms a certain angle with the working axis. The workpiece rotates while being fed at a constant speed, making the heating more uniform. The roller between the furnace bodies is made of 304 non-magnetic stainless steel and is water-cooled. The rollers in other parts are made of 45# steel and surface quenched.
Roller grouping: The feeding group, sensor group and discharging group are controlled independently, which is conducive to continuous heating without gaps between workpieces.
Temperature closed-loop control: Both quenching and tempering use infrared thermometers and PLC systems to form a closed-loop control system for precise temperature control.
Industrial computer system: Real-time display of the current working parameters, workpiece parameter memory, storage, printing, fault display, alarm and other functions.

Why Choose Ruixinsheng Technology?

Independent Intellectual Property Rights:

Master the core technology and independent research and development of internationalleading induction heating system.

Energy-Saving and Efficient:

Meet international standards for electrical and load design standards, power factor up to0.98, and energy saving 20%.

Environmental Protection and Safety:

Furnace structure according to the national standards, scientific and technologicalreasonable personalized design, ensure the safety and reliability of the device.

Stable and Reliable:

The world's first-class component selection, scientific and reasonable equipmenttechnology, complete protection functions, the primary fault is close to zero.

Intelligent Control:

Equipment management system, can achieve production management, quality control andother functions, to achieve remote diagnosis of equipment, data acquisition, transmissionand other monitoring.

Send Inquiry

Tell us your needs, and we will recommend you the melting furnace that suits you.
