Mini Melting furnace
keyword:
Melting and heating equipment
hiddenValue
- Product description
-
Application
The high-frequency melting furnace is mainly used for the melting and heating treatment of precious metal materials such as gold, silver, copper, tin, aluminum, iron, stainless steel, platinum, etc. The melting range is from 1KG to 750KG. It mainly uses the crucible container to instantaneously heat up the precious metal to carry out smelting, purification and forging processes. The medium-high frequency melting has a good electromagnetic stirring effect, which is conducive to the uniform temperature and structure of the molten metal, and is conducive to removing slag and reducing impurities.
Mini melting furnace is composed of three parts: intermediate frequency power supply, furnace body and water cooling system.
The furnace body is composed of furnace shell, induction coil, furnace lining, tilting hydraulic system or a reduction box, etc.
Frequency range, high frequency 30-80KHZ, medium frequency 1-10KHZ, the induction coil and compensation capacitor can be designed comprehensively considering melting volume, electromagnetic stirring effect, heating efficiency, working environment and other factors to determine the output frequency.
Product characteristics:
1. Melting furnace adopts imported power IGBT device, more integrated, miniaturized, effective output power up to 95%.
2. Easy to change different weights, different materials, and different smelting methods of the body, can adapt to a variety of smelting requirements, including vertical smelting requirements, manual smelting requirements, electric smelting, school laboratory smelting.
3. The ultra-small medium frequency induction heating power supply is 30% more energy saving than the traditional thyristor.
Technical Parameters
Model Steel/Iron Aluminium Copper/Gold/Silver/Noble metal LHRL-15KW 3KG 3KG 3KG,5KG,10KG LHRL-25KW 5KG 5KG 20KG LHRL-35KW 10KG 10KG 30KG LHRL-45KW 18KG 18KG 50KG LHRL-70KW 25KG 25KG 100KG LHRL-90KW 40KG 40KG 120KG LHRL-110KW 50KG 50KG 150KG LHRL-160KW 100KG 100KG 250KG LHRL-200KW 150KG 200KG 350KG LHRL-300KW 200KG 300KG 500KG LHRL-400KW 250KG 400KG 600KG
Why Choose Ruixinsheng Technology?
Independent Intellectual Property Rights:
Master the core technology and independent research and development of internationalleading induction heating system.
Energy-Saving and Efficient:
Meet international standards for electrical and load design standards, power factor up to0.98, and energy saving 20%.
Environmental Protection and Safety:
Furnace structure according to the national standards, scientific and technologicalreasonable personalized design, ensure the safety and reliability of the device.
Stable and Reliable:
The world's first-class component selection, scientific and reasonable equipmenttechnology, complete protection functions, the primary fault is close to zero.
Intelligent Control:
Equipment management system, can achieve production management, quality control andother functions, to achieve remote diagnosis of equipment, data acquisition, transmissionand other monitoring.
Send Inquiry
Tell us your needs, and we will recommend you the melting furnace that suits you.
